MSI PRO B760M-A (WIFI) DDR5 MOTHERBOARD

(3 Years Warranty)

Model – B760M-A

Chipset – Intel B760

Cpu Support – Supports 12th/13th Gen Intel® Core™ Processors, Pentium® Gold And Celeron® Processors ,

Lga – 1700

Memory – 4x Ddr5, Maximum Memory Capacity 192gb

Memory Support – Ddr5 6800+(Oc)/ 6600(Oc)/ 6400(Oc)/ 6200(Oc)/ 6000(Oc)/ 5800(Oc)/ 5600(Jedec)/ 5400(Jedec)/ 5200(Jedec)/ 5000(Jedec)/ 4800(Jedec) Mhz

Max. Overclocking Frequency: – 1dpc 1r Max Speed Up To 6800+ Mhz , 1dpc 2r Max Speed Up To 6400+ Mhz , 2dpc 1r Max Speed Up To 6000+ Mhz , 2dpc 2r Max Speed Up To 5600+ Mhz , Supports Intel® Xmp 3.0 Oc , Supports Dual-controller Dual-channel Mode , Supports Non-ecc, Un-buffered Memory

Onboard Graphics – 2x Hdmi™ , Support Hdmi™ 2.1, Maximum Resolution Of 4k 60hz* , 2x Displayport Support Dp 1.4, Maximum Resolution Of 4k 60hz* , Support Dp 1.4, Maximum Resolution Of 4k 60hz* , *available Only On Processors Featuring Integrated Graphics. Graphics Specifications May Vary Depending On The Cpu Installed.

Expansion Slot – 2x Pci-e X16 Slot
– 1x Pci-e X1 Slot
– Pci_e1 Gen Pcie 4.0 Supports Up To X16 (From Cpu)
– Pci_e2 Gen Pcie 3.0 Supports Up To X1 (From Chipset)
– Pci_e3 Gen Pcie 4.0 Supports Up To X4 (From Chipset)

Storage – 2x M.2 , M.2_1 Source (From Cpu) Supports Up To Pcie 4.0 X4 , Supports 2280/2260/2242 Devices , M.2_1 Source (From Cpu) Supports Up To Pcie 4.0 X4 , Supports 2280/2260/2242 Devices , M.2_2 Source (From Chipset) Supports Up To Pcie 4.0 X4 / Sata Mode, Supports 2280/2260/2242 Devices , 4x Sata 6g , Sata8 Will Be Unavailable When Installing M.2 Sata Ssd In The M2_2 Slot.

Raid – Supports Raid 0, Raid 1, Raid 5 And Raid 10 For Sata Storage Devices

Usb – 2x Usb 2.0 (Rear) , 4x Usb 2.0 (Front) , 2x Usb 3.2 Gen1 Type A (Rear) , 4x Usb 3.2 Gen1 Type A (Front), 1x Usb 3.2 Gen1 Type C (Front) , 2x Usb 3.2 Gen2 Type A (Rear)

Lan – Realtek® Rtl8125bg 2.5g Lan

Wireless – Intel® Wi-fi 6e , The Wireless Module Is Pre-installed In The M.2 (Key-e) Slot , Supports Mu-mimo Tx/rx, 2.4ghz / 5ghz / 6ghz* (160mhz) Up To 2.4gbps , Supports 802.11 A/ B/ G/ N/ Ac/ Ax

Bluetooth – Supports Bluetooth® 5.3, Fips, Fisma , ** Bluetooth 5.3 Will Be Ready In Windows 10 Build 21h1 And Windows 11.

Audio – Realtek® Alc897 Codec , 7.1-channel High Definition Audio

Internal I/o – 1x Power Connector(Atx_pwr) , 2x Power Connector(Cpu_pwr) , 1x Cpu Fan , 1x Pump Fan , 2x System Fan , 2x Front Panel (Jfp) , 1x Chassis Intrusion (Jci) , 1x Front Audio (Jaud) , 1x Com Port (Jcom) , 2x Addressable V2 Rgb Led Connector (Jargb_v2) , 1x Rgb Led Connector(Jrgb) , 1x Tpm Pin Header(Support Tpm 2.0) , 4x Usb 2.0 Ports , 4x Usb 3.2 Gen1 Type A Ports , 1x Usb 3.2 Gen1 Type C Ports

Led Feature – 4x Ez Debug Led

Back Panel Ports – Keyboard / Mouse , Displayport , Usb 3.2 Gen 1 5gbps (Type-a) , 2.5g Lan , Wi-fi / Bluetooth , Audio Connectors , Usb 2.0 , Hdmi™ , Usb 3.2 Gen 2 10gbps (Type-a)

Operating System – Support For Windows® 11 64-bit, Windows® 10 64-bit

Pcb Dimension (W × L) – Matx
