(03 Years Warranty)
Chipset – Amd B850
Cpu
Cpu Support – Amd Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors
Socket – Am5
Memory
Memory Slots – 4× Ddr5 Udimm
Maximum Capacity – 256gb
Memory Speed (Oc) – Ddr5 8200 – 5600 Mt/s
Memory Speed (Jedec) – Ddr5 5600 – 4800 Mt/s
Channel Support – Dual Channel
Memory Type – Non-ecc, Un-buffered
Memory Oc Support – Amd Expo™
Cudimm Support – Yes (Clock Driver Bypass Mode Only*)
Ryzen™ 9000 Series Max Memory Oc
1dpc 1r – Up To 8200+ Mt/s
1dpc 2r – Up To 6400+ Mt/s
2dpc 1r – Up To 6400+ Mt/s
2dpc 2r – Up To 6000+ Mt/s
Onboard Graphics
Video Outputs – 1× Hdmi™, 1× Displayport
Hdmi Version – Hdmi™ 2.1 (4k @ 60hz)
Displayport Version – Displayport 1.4 (4k @ 60hz)
Requirement – Processor With Integrated Graphics
Expansion Slots
Pcie Slots – 1× Pcie X16, 2× Pcie X1
Slot Configuration
Pci_e1 – Pcie 3.0 X1 (Chipset)
Pci_e2 – Pcie 4.0 X16 (Cpu)
Pci_e3 – Pcie 3.0 X1 (Chipset)
Pci_e2 Lane Support By Cpu
Ryzen™ 9000 / 7000 – Pcie 4.0 X16
Ryzen™ 8700 / 8600 / 8400 – Pcie 4.0 X8
Ryzen™ 8500 / 8300 – Pcie 4.0 X4
Audio
Audio Codec – Realtek® Alc897
Audio Channels – 7.1-channel High Definition Audio
Storage
M.2 Slots – 2
M.2_1 – Pcie 5.0 X4 (Cpu), 2280 / 2260
M.2_2 – Pcie 4.0 X4 (Cpu), 2280 / 2260
Sata Ports – 4× Sata 6gb/s
M.2 Slot Speed By Cpu
M.2_1
Ryzen™ 9000 / 7000 – Pcie 5.0 X4
Ryzen™ 8000 – Pcie 4.0 X4
M.2_2
Ryzen™ 9000 / 8700 / 8600 / 8400 / 7000 – Pcie 4.0 X4
Ryzen™ 8500 / 8300 – Pcie 4.0 X2
Raid
Sata Raid – Raid 0 / Raid 1 / Raid 10
Nvme Raid – Raid 0 / Raid 1
Usb
Rear Usb
Usb 5gbps Type-a – 4
Usb 10gbps Type-a – 3
Usb 10gbps Type-c – 1
Front Usb
Usb 2.0 – 4
Usb 5gbps Type-a – 2
Usb 10gbps Type-c – 1
Lan
Ethernet – Realtek® 8125d 2.5gb Lan
Wireless & Bluetooth
Wi-fi – Wi-fi 6e
Bands – 2.4ghz / 5ghz / 6ghz (160mhz)
Max Speed – Up To 2.4gbps
Standards – 802.11 A / B / G / N / Ac / Ax
Bluetooth – Bluetooth® 5.3
Internal Connectors
Atx Power – 1
Cpu Power – 2
Cpu Fan Header – 1
Pump / System Fan – 1
System Fan Headers – 3
Argb V2 Headers – 3
Rgb Header – 1
Tpm Header – Tpm 2.0
Front Audio – 1
Led Features
Ez Debug Led – 4
Ez Memory Detection Led – 1
Rear I/o Ports
Clear Cmos Button
Flash Bios Button
Hdmi™
Displayport 1.4
Usb 5gbps Type-a
Usb 10gbps Type-a
Usb 10gbps Type-c
2.5g Lan
Wi-fi / Bluetooth
Hd Audio Jacks
Other
Form Factor – Matx
Pcb Size – 243.84 × 243.84 Mm
Operating System – Windows® 11 64-bit
