(3 Years Warranty)
Chipset – Intel B760
Cpu Support – Supports 12th/13th Gen Intel® Core™ Processors, Pentium® Gold And Celeron® Processors , Lga 1700
Memory – 4x Ddr5, Maximum Memory Capacity 192gb
Memory Support – Ddr5 6800+(Oc)/ 6600(Oc)/ 6400(Oc)/ 6200(Oc)/ 6000(Oc)/ 5800(Oc)/ 5600(Jedec)/ 5400(Jedec)/ 5200(Jedec)/ 5000(Jedec)/ 4800(Jedec) Mhz
Max. Overclocking Frequency – 1dpc 1r Max Speed Up To 6800+ Mhz , 1dpc 2r Max Speed Up To 6400+ Mhz , 2dpc 1r Max Speed Up To 6000+ Mhz , 2dpc 2r Max Speed Up To 5600+ Mhz , Supports Intel® Xmp 3.0 Oc , Supports Dual-controller Dual-channel Mode , Supports Non-ecc, Un-buffered Memory
Onboard Graphics – 1x Hdmi™ (Support Hdmi™ 2.1 With Hdr, Maximum Resolution Of 4k 60hz*) , 1x Displayport (Support Dp 1.4, Maximum Resolution Of 4k 60hz*) , Support Dp 1.4, Maximum Resolution Of 4k 60hz* (*available Only On Processors Featuring Integrated Graphics. Graphics Specifications May Vary Depending On The Cpu Installed.)
Expansion Slot – 5x Pci-e X16 Slot , Pci_e1 Gen Pcie 4.0 Supports Up To X16 (From Cpu) , Pci_e2 Gen Pcie 3.0 Supports Up To X1 (From Chipset) , Pci_e3 Gen Pcie 4.0 Supports Up To X4 (From Chipset) , Pci_e4 Gen Pcie 3.0 Supports Up To X1 (From Chipset) , Pci_e5 Gen Pcie 3.0 Supports Up To X1 (From Chipset)
Storage – 2x M.2 , M.2_1 Source (From Cpu) Supports Up To Pcie 4.0 X4 , Supports 22110/2280/2260/2242 Devices , M.2_2 Source (From Chipset) Supports Up To Pcie 4.0 X4 / Sata Mode, Supports 2280/2260/2242 Devices , 4x Sata 6g , * Sata8 Will Be Unavailable When Installing M.2 Sata Ssd In The M2_2 Slot.
Raid – Supports Raid 0, Raid 1, Raid 5 And Raid 10 For Sata Storage Devices
Usb – 4x Usb 2.0 (Rear) , 4x Usb 2.0 (Front) , 2x Usb 3.2 Gen1 Type A (Front) , 1x Usb 3.2 Gen1 Type C (Front) , 3.2 Gen1 Type A (Front) , 2x Usb 3.2 Gen2 Type A (Rear) , 1x Usb 3.2 Gen2 Type C (Rear)
Lan – Realtek® Rtl8125bg 2.5g Lan
Wireless / Bluetooth – Intel® Wi-fi 6e , Supports Bluetooth® 5.3, Fips, Fisma
Audio – Realtek® Alc897 Codec , 7.1-channel High Definition Audio (Supports S/pdif Output)
Internal I/O – 1x Power Connector(Atx_pwr) , 2x Power Connector(Cpu_pwr) , 1x Cpu Fan , 1x Pump Fan , 5x System Fan , 2x Front Panel (Jfp) , 1x Chassis Intrusion (Jci) , 1x Front Audio (Jaud) , 1x Printer Port (Jlpt) , 1x Com Port (Jcom) , 1x Tbt Connector (Jtbt, Supports Rtd3) , 2x Addressable V2 Rgb Led Connector (Jargb_v2) , 1x Rgb Led Connector(Jrgb) , 1x Tpm Pin Header(Support Tpm 2.0) , 4x Usb 2.0 Ports , 2x Usb 3.2 Gen1 Type A Ports , 1x Usb 3.2 Gen1 Type C Ports
Led Feature – 4x Ez Debug Led
