(03 Month Warranty)
Cpu – Support For 9th And 8th Generation Intel® Core™ I9 / I7 / I5 / I3 / Pentium® / Celeron® Processors (Lga1151 Package)
L3 Cache – Varies By Cpu
(Refer To “cpu Support List” For More Information)
Chipset – Intel® B365m Express Chipset
Memory – 4 X Ddr4 Dimm Sockets, Supporting Up To 64 Gb System Memory
Memory Architecture – Dual Channel
Supported Memory Speeds – Ddr4 2666 / 2400 / 2133 Mhz
Memory Type Support – Ecc Un-buffered Dimm (Operates In Non-ecc Mode), Non-ecc Un-buffered Dimm (1rx8 / 2rx8 / 1rx16), Xmp Memory Modules
To Support 2666 Mhz Or Xmp, A 9th Or 8th Gen Intel® Core™ I9/i7/i5 Processor Is Required
(Refer To “memory Support List” For More Information)
Onboard Graphics – Integrated Intel® Hd Graphics
Display Outputs –
• 1 X D-sub (Max 1920×1200@60hz)
• 1 X Dvi-d (Max 1920×1200@60hz, No D-sub Adapter Support)
• 1 X Hdmi (Max 4096×2160@30hz, Hdmi 1.4, Hdcp 2.2)
Display Support – Up To 3 Displays Simultaneously
Shared Memory – Max 1 Gb (Actual Support May Vary By Cpu)
Audio – Realtek® Alc887 Codec, High Definition Audio, 2/4/5.1/7.1-channel, S/pdif Out Support
To Enable 7.1-channel Audio, Use An Hd Front Panel Audio Module And Configure Via Driver
Lan – Realtek® Gbe Lan (10/100/1000 Mbit)
Expansion Slots –
• 1 X Pci Express X16 Slot (Running At X16)
• 1 X Pci Express X4 Slot
• 1 X Pci Express X1 Slot
(All Pcie Slots Conform To Pcie 3.0 Standard)
For Best Performance, Install A Single Gpu In The Pciex16 Slot
Storage Interface –
• 1 X M.2 Connector (Socket 3, M Key, Type 2242/2260/2280 Sata & Pcie X4/x2 Ssd Support)
• 6 X Sata 6gb/s Connectors
• Raid 0, 1, 5, 10 Support
• Intel® Optane™ Memory Ready
(Refer To “internal Connectors” For Installation Details)
Usb –
• 6 X Usb 3.1 Gen 1 (4 Rear, 2 Internal)
• 6 X Usb 2.0/1.1 (2 Rear, 4 Internal)
Internal I/o Connectors –
• 1 X 24-pin Atx Main Power Connector
• 1 X 8-pin Atx 12v Power Connector
• 1 X Cpu Fan Header
• 2 X System Fan Headers
• 1 X Rgb Led Strip Header
• 1 X M.2 Socket 3 Connector
• 6 X Sata 6gb/s Connectors
• 1 X Front Panel Header
• 1 X Front Panel Audio Header
• 1 X S/pdif Out Header
• 1 X Usb 3.1 Gen 1 Header
• 2 X Usb 2.0/1.1 Headers
• 1 X Tpm Header (2×6 Pin, For Gc-tpm2.0_s Module Only)
• 1 X Serial Port Header
• 1 X Parallel Port Header
• 1 X Clear Cmos Jumper
Back Panel Connectors –
• 1 X Ps/2 Keyboard/mouse Port
• 1 X D-sub Port
• 1 X Dvi-d Port
• 1 X Hdmi Port
• 4 X Usb 3.1 Gen 1 Ports
• 2 X Usb 2.0/1.1 Ports
• 1 X Rj-45 Lan Port
• 3 X Audio Jacks
I/o Controller – Ite® I/o Controller Chip
Hardware Monitoring – Voltage, Temperature, And Fan Speed Detection, Overheating Warning, Fan Fail Warning, Fan Speed Control
Fan Speed Control Support Depends On The Installed Cooler
Bios – Dualbios™ (2 X 128 Mbit Flash), Ami Uefi Bios, Pnp 1.0a, Dmi 2.7, Wfm 2.0, Sm Bios 2.7, Acpi 5.0
