( 03 Month Warranty )
Cpu
Support For 9th And 8th Generation Intel® Core™ I9 Processors/intel® Core™ I7 Processors/intel® Core™ I5 Processors/intel® Core™ I3 Processors/intel® Pentium® Processors/intel® Celeron® Processors In The Lga1151 Package
L3 Cache Varies With Cpu
(Please Refer “Cpu Support List” For More Information.)
Chipset
Intel® B365 Express Chipset
Memory
4 X Ddr4 Dimm Sockets Supporting Up To 64 Gb Of System Memory
Dual Channel Memory Architecture
Support For Ddr4 2666/2400/2133 Mhz Memory Modules
Support For Ecc Un-buffered Dimm 1rx8/2rx8 Memory Modules (Operate In Non-ecc Mode)
Support For Non-ecc Un-buffered Dimm 1rx8/2rx8/1rx16 Memory Modules
Support For Extreme Memory Profile (Xmp) Memory Modules
* To Support 2666 Mhz Or Xmp Memory, You Must Install A 9th Or 8th Generation Intel® Core™ I9/i7/i5 Processor.
(Please Refer “Memory Support List” For More Information.)
Onboard Graphics
Integrated Graphics Processor-intel® Hd Graphics Support:
1 X Dvi-d Port, Supporting A Maximum Resolution Of 1920×1200@60 Hz
* The Dvi-d Port Does Not Support D-sub Connection By Adapter.
1 X Displayport, Supporting A Maximum Resolution Of 4096×2304@60 Hz
* Support For Displayport 1.2 Version, Hdcp 2.2, And Hdr.
1 X Hdmi Port, Supporting A Maximum Resolution Of 4096×2160@30 Hz
* Support For Hdmi 1.4 Version And Hdcp 2.2.
Support For Up To 3 Displays At The Same Time
Maximum Shared Memory Of 1 Gb
Audio
Realtek® Alc892 Codec
High Definition Audio
2/4/5.1/7.1-channel
Support For S/pdif Out
Lan
Intel® Gbe Lan Chip (10/100/1000 Mbit)
Expansion Slots
1 X Pci Express X16 Slot, Running At X16 (Pciex16)
* For Optimum Performance, If Only One Pci Express Graphics Card Is To Be Installed, Be Sure To Install It In The Pciex16 Slot.
1 X Pci Express X16 Slot, Running At X4 (Pciex4)
1 X Pci Express X1 Slot
(All Of The Pci Express Slots Conform To Pci Express 3.0 Standard.)
1 X M.2 Socket 1 Connector For The Wireless Communication Module (M2_wifi)
Multi-graphics Technology
Support For Amd Quad-gpu Crossfire™ And 2-way Amd Crossfire™ Technologies
Storage Interface
