(03 Month Warranty)
Socket – Lga 1150
Cpu Support – 5th Gen / 4th Gen Intel Core I7 / I5 / I3 / Pentium / Celeron, Intel Xeon
Chipset – Intel H97
Memory Type – Ddr3 / Ddr3l
Memory Slots – 4 Dimm
Memory Speed – 1600 / 1333 / 1066 Mhz
Max Memory – 32gb
Memory Channel – Dual Channel
Xmp Support – Yes (1.3 / 1.2)
Bios – Dual 64mb Ami Uefi (Main + Backup)
Graphics – Intel Hd Graphics 4400 / 4600 (Integrated)
Max Resolution (Hdmi) – 4096×2304 @ 24hz
Multi-monitor Support – Yes (Triple Display)
Graphics Outputs – Hdmi, Dvi-d, Vga
Audio – 7.1 Channel Hd Audio (Realtek Alc1150)
Audio Features – Dts Connect, Purity Sound 2, 115db Snr, Headphone Amp (600ω Support)
Lan – Gigabit Lan (Intel I218v)
Pcie X16 Slots – 2 (Gen3 X16 + Gen2 X4)
Pcie X1 Slots – 2
Pci Slots – 3
Multi-gpu Support – Amd Crossfirex
Storage – 6 X Sata3 (6gb/s)
Raid Support – Raid 0 / 1 / 5 / 10
Usb Ports (Rear) –
4 X Usb 3.1 Gen1
4 X Usb 2.0 (Incl. Fatal1ty Port)
Video Outputs (Rear) – Hdmi, Dvi-d, Vga
Audio Ports (Rear) – 7.1 Channel Audio + Optical Spdif
Lan Port – 1 X Rj-45
Internal Connectors –
Usb 3.1 Gen1 Header
Usb 2.0 Headers
Tpm Header
Com Header
Thunderbolt Aic Header
Fan & Power Connectors
