(03 Month Warranty)
Cpu Socket – Am4
Supported Processors – Amd Ryzen 2000 / 3000 / 4000g / 5000 / 5000g Series
Power Phase Design – 6 Phase
Max Cpu Power – Up To 105 W
Chipset – Amd B450 (Promontory)
Memory
Memory Type – Ddr4
Memory Channels – Dual Channel
Dimm Slots – 2
Max Memory – 64 Gb
Memory Speeds – Ddr4 3200 / 2933 / 2667 / 2400 / 2133
Ecc Support – Ecc & Non-ecc (Unbuffered)
Xmp Support – Yes
Bios
Bios Type – 128 Mb Ami Uefi Bios
Features – Plug And Play, Acpi 5.1, Smbios 2.3, Dram Voltage Adjustment
Graphics (With Apu)
Integrated Gpu – Amd Radeon Vega Graphics (Apu Only)
Directx – Directx 12
Display Outputs – D-sub, Dvi-d, Hdmi
Max Hdmi Resolution – 4096×2160 @24hz / 3840×2160 @30hz
Max Dvi-d Resolution – 1920×1200 @60hz
Max Vga Resolution – 2048×1536 @60hz
Multi-monitor Support – Triple Monitor
Audio
Audio Codec – Realtek Alc887 / Alc897
Audio Channels – 7.1 Channel Hd Audio
Lan
Lan Chipset – Realtek Rtl8111h
Lan Speed – Gigabit (10/100/1000 Mb/s)
Expansion Slots
Pcie X16 – 1 × Pcie 3.0 X16
Pcie X1 – 1 × Pcie 2.0 X1
Storage
Sata Ports – 4 × Sata3 6.0 Gb/s
M.2 Slot – 1 × Ultra M.2 (Pcie Gen3 X4 / Sata)
Raid Support – Raid 0 / 1 / 10
Nvme Boot Support – Yes
Internal Connectors
Cpu Fan Header – 1 × 4-pin
Chassis Fan Headers – 2
Usb 2.0 Headers – 2 (4 Ports)
Usb 3.1 Gen1 Header – 1 (2 Ports)
Tpm Header – 1
Com Port Header – 1
Front Audio Header – 1
Power Connectors – 24-pin Atx + 4-pin Cpu
Rear I/o Ports
Ps/2 Port – 1
Hdmi – 1
Dvi-d – 1
Vga (D-sub) – 1
Usb 3.1 Gen1 – 4
Usb 2.0 – 2
Lan (Rj-45) – 1
Audio Jacks – Line-in / Front Speaker / Microphone
