(03 Month Warranty)
Cpu – Supports 9th And 8th Gen Intel® Core™ Processors (Socket 1151)
Cpu Power Limit – Supports Cpu Up To 95w
Cpu Features – Digi Power Design, Intel® Turbo Boost 2.0 Technology
Chipset – Intel® B360M
Memory Type – Dual Channel Ddr4 Memory Technology
Memory Slots – 4 X Ddr4 Dimm Slots
Memory Support – Ddr4 2666 / 2400 / 2133 Mhz, Non-ecc, Un-buffered
Ecc Support – Supports Ecc Udimm (Operates In Non-ecc Mode)
Max Memory – Up To 128gb*
Xmp Support – Supports Intel® Extreme Memory Profile (Xmp) 2.0
Dimm Slot Quality – 15μ Gold Contact In Dimm Slots
Bios – 128mb Ami Uefi Legal Bios With Multilingual Gui
Bios Features – Acpi 6.0, Smbios 2.7, Voltage Multi-adjustment (Cpu, Dram, Pch 1.0v, Vccio, Vccsa, Vccst)
Integrated Graphics – Intel® Uhd Graphics (Requires Supported Cpu)
Graphics Features – Intel® Quick Sync Video, Intru™ 3d, Clear Video Hd, Insider™
Graphics Apis – Supports Directx 12
Hardware Decode/encode – Avc/h.264, Hevc/h.265 (8-bit & 10-bit), Vp8, Vp9, Mpeg2, Mjpeg, Vc-1
Display Outputs – 1 X Hdmi, 1 X Dvi-d, 1 X D-sub
Triple Monitor Support – Yes
Hdmi Max Resolution – 4096×2160 @ 30hz
Dvi-d Max Resolution – 1920×1200 @ 60hz
D-sub Max Resolution – 1920×1200 @ 60hz
Hdmi Features – Auto Lip Sync, Deep Color (12bpc), Xvycc, Hbr Audio
Hdcp Support – Hdcp 2.2 On Hdmi & Dvi-d
4k Playback – Supports 4k Ultra Hd Via Hdmi
Audio Codec – Realtek Alc892
Audio Channels – 7.1 Ch Hd Audio With Content Protection
Audio Features – Premium Blu-ray Audio, Surge Protection, Elna Audio Caps
Lan Controller – Intel® I219v Gigabit Lan (10/100/1000 Mb/s)
Lan Features – Wake-on-lan, Lightning/esd Protection, Energy Efficient Ethernet (802.3az), Pxe
Pcie X16 Slots – 2 X Pcie 3.0 X16 (Single At X16, Dual At X16/x4)*
Pcie X1 Slots – 2 X Pcie 3.0 X1
Multi-gpu Support – Supports Amd Quad Crossfirex™ And Crossfirex™
Wi-fi Slot – 1 X M.2 (Key E) For Wifi/bt Pcie Module & Intel® Cnvi
Sata Ports – 6 X Sata3 6.0 Gb/s (Supports Ncq, Ahci, Hot Plug)*
M.2 Slot 1 (M2_1) – Pcie Gen3 X4 (Up To 32 Gb/s), Supports 2230/2242/2260/2280 M Key Nvme Ssds
M.2 Slot 2 (M2_2) – Pcie Gen3 X1 Or Sata3 (6 Gb/s), Supports 2230/2242/2260/2280 M Key Ssds
Intel® Optane™ Support – Yes (M2_1 Only)
Boot Support – Supports Nvme Ssd As Boot Disk
U.2 Support – Supports Asrock U.2 Kit
Internal Headers – 1 X Com Port, 1 X Tpm, 1 X Chassis Intrusion/speaker
Power Connectors – 1 X 24-pin Atx, 1 X 8-pin 12v
Fan Headers –
1 X Cpu Fan (4-pin, Max 1a / 12w)
1 X Cpu/water Pump Fan (4-pin, Max 2a / 24w)
2 X Chassis/water Pump Fan (4-pin, Max 2a / 24w)
Fan Control – Smart Fan Speed Control, 3-pin/4-pin Auto Detection
Usb Headers –
2 X Usb 2.0 (Supporting 3 Ports Total)
1 X Usb 3.1 Gen1 (Supports 2 Ports)
Rear I/o Ports –
1 X Ps/2 Mouse, 1 X Ps/2 Keyboard
1 X Hdmi, 1 X Dvi-d, 1 X D-sub
2 X Usb 2.0
2 X Usb 3.1 Gen1
1 X Usb 3.1 Gen2 Type-a
1 X Usb 3.1 Gen2 Type-c
1 X Rj-45 Lan
3 X Audio Jacks (Line In, Front Speaker, Microphone)
Software Utilities – Asrock A-tuning, Live Update & App Shop
Uefi Features – Ez Mode, Full Hd Uefi, My Favorites, Instant Flash, Internet Flash
Monitoring Features –
Temperature: Cpu, Water Pump, Chassis
Fan Speed: Cpu, Water Pump, Chassis
Quiet Fan (Auto Adjusts Chassis Fan By Cpu Temp)
Voltage Monitoring: +12v, +5v, +3.3v, Cpu Vcore, Dram, Pch 1.0v
Case Open Detection
Form Factor – Micro Atx (24.4 Cm X 24.4 Cm)
Design – Solid Capacitor Design
Operating System Support – Microsoft Windows® 10 64-bit / 11 64-bit
