(03 Month Warranty)
CPU – Supports AMD Socket Am4 A-series Apus (Bristol Ridge) And Ryzen Series Cpus (Matisse, Picasso, Summit Ridge, Raven Ridge And Pinnacle Ridge) – Digi Power Design – 7 Power Phase Design – Supports CPU Up To 65w
Chipset – AMD Promontory A320
Memory – Dual Channel Ddr4 Memory Technology – 2 X Ddr4 Dimm Slots – Supports Ddr4 Up To 3200mhz (Oc Depending On CPU) – Supports Ecc & Non-ecc Un-buffered Memory – Max Capacity Up To 32gb – 15μ Gold Contact In Dimm Slots
BIOS – 128mb Ami UEFI Legal BIOS With GUI Support – Supports Plug And Play – Acpi 5.1 Compliance – Smbios 2.3 Support – Dram Voltage Multi-adjustment
Graphics – Integrated AMD Radeon Vega Graphics (Ryzen Apu) – Integrated Radeon R-series Graphics (A-series Apu) – DirectX 12, Pixel Shader 5.0 – Shared Memory Up To 16gb – HDMI, Dvi-d And D-sub Outputs – HDMI Supports Up To 4k (4096×2160@24hz / 3840×2160@30hz) – Supports Triple Monitor – Hdcp 1.4 Support – Full Hd Blu-ray Playback Support
Audio – 7.1 Channel Hd Audio (Realtek Alc887 Audio Codec) – Supports Surge Protection – Elna Audio Caps
LAN – Pcie X1 Gigabit LAN 10/100/1000 Mb/s – Realtek Rtl8111gr – Supports Wake-on-lan – Esd Protection – Energy Efficient Ethernet 802.3az – Pxe Support
Slots – 1 X Pci Express 3.0 X16 Slot (X16/x8/x4 Mode Depending On CPU) – 1 X Pci Express 2.0 X1 Slot – Supports NVMe SSD As Boot
Storage – 4 X Sata3 6.0 Gb/s Connectors – Supports Raid 0, 1 And 10 – 1 X Ultra M.2 Socket (Pcie Gen3 X4/x2 & Sata Support Depending On CPU) – Supports NVMe SSD As Boot
Connector – 1 X Print Port Header – 1 X Com Port Header – 1 X Tpm Header – 1 X Chassis Intrusion Header – 1 X CPU Fan Connector (4-PIN) – 2 X Chassis Fan Connectors – 1 X 24-PIN Atx Power Connector – 1 X 4-PIN 12v Power Connector – 1 X Front Panel Audio Header – 2 X USB 2.0 Headers – 1 X USB 3.1 Gen1 Header
Rear Panel I/o – 1 X Ps/2 Port – 1 X D-sub Port – 1 X Dvi-d Port – 1 X HDMI Port – 2 X USB 2.0 Ports – 4 X USB 3.1 Gen1 Ports – 1 X Rj-45 LAN Port – Hd Audio Jacks
