AMD RYZEN 7 7800X3D TRAY PROCESSOR (8 CORES 16 THREADS)

(3 Years Warranty)

Name – Amd Ryzen™ 7 7800x3d

Family – Ryzen

Series – Ryzen 7000 Series

Form Factor – Desktops, Boxed Processor

Market Segment – Enthusiast Desktop

Amd Pro Technologies – No

Consumer Use – Yes

Regional Availability – Global

Former Codename – Raphael Am5

Architecture – Zen 4

# Of Cpu Cores – 8

Multithreading (Smt) – Yes

# Of Threads – 16

Max. Boost Clock – Up To 5.0 Ghz

Base Clock – 4.2 Ghz

L1 Cache – 512 Kb

L2 Cache – 8 Mb

L3 Cache – 96 Mb

Default Tdp – 120w

Processor Technology For Cpu Cores – Tsmc 5nm Finfet

Processor Technology For I/o Die – Tsmc 6nm Finfet

Cpu Compute Die (Ccd) Size – 71 Mm²

I/o Die (Iod) Size – 122 Mm²

Package Die Count – 2

Amd Expo™ Memory Overclocking Technology – Yes

Precision Boost Overdrive – Yes

Curve Optimizer Voltage Offsets – Yes

Amd Ryzen™ Master Support – Yes

Cpu Socket – Am5

Supporting Chipsets – A620, X670e, X670, B650e, B650

Cpu Boost Technology – Precision Boost 2

Instruction Set – X86-64

Supported Extensions – Aes, Amd-v, Avx, Avx2, Avx512, Fma3, Mmx-plus, Sha, Sse, Sse2, Sse3, Sse4.1, Sse4.2, Sse4a, Ssse3, X86-64

Thermal Solution (Pib) – Not Included

Recommended Cooler – Liquid Cooler Recommended For Optimal Performance

Max. Operating Temperature (Tjmax) – 89°c

Os Support – Windows 11 (64-bit), Windows 10 (64-bit), Rhel X86 64-bit, Ubuntu X86 64-bit

Native Usb 3.2 Gen 2 Ports – 4

Native Usb 3.2 Gen 1 Ports – 0

Native Usb 2.0 Ports – 1

Native Sata Ports – 0

Pci Express® Version – Pcie® 5.0

Native Pcie® Lanes (Total/usable) – 28 / 24

Additional Usable Pcie Lanes From Motherboard:

X670e – 12x Gen4

X670 – 12x Gen4

B650e – 8x Gen4

B650 – 8x Gen4

Nvme Support – Boot, Raid0, Raid1, Raid10

System Memory Type – Ddr5

Memory Channels – 2

Max. Memory – 128 Gb

System Memory Subtype – Udimm

Max Memory Speed:

2x1r – Ddr5-5200

2x2r – Ddr5-5200

4x1r – Ddr5-3600

4x2r – Ddr5-3600

Ecc Support – Yes (Requires Motherboard Support)

Graphics Model – Amd Radeon™ Graphics

Graphics Core Count – 2

Graphics Frequency – 2200 Mhz

Usb Type-c® Displayport™ Alternate Mode – Yes

Supported Technologies – Amd Expo™ Technology, Amd Ryzen™ Technologies
